How to Build a Stylish DIY Chevron Storage Rack for Wine, Paint, or Anything Else!
If you’ve ever admired those sleek, tilted wine cellars or chevron-patterned shelves that maximize storage, you’re in for a treat. Why not take it a step further and create your own chevron-inspired rack that not only stores wine but can hold anything from food containers to spray paint cans in your workshop? It’s the perfect DIY project for anyone looking to save space, add personality to their home, and tackle storage in style!
The best part about DIY furniture is the ability to customize it to your exact needs and space. You can create a piece that perfectly fits that awkward corner of your room without wasting precious square footage.
Let’s dive into how you can build your very own chevron storage rack with a personal touch and practical design.
Materials You’ll Need:
- 5 sheets of 1″ x 8″ x 8′ common wood boards (pick the least expensive kind if you’re going for a rustic, functional look)
- Minwax Wood Finish Stain in Unique Walnut 224
- Minwax Pre-Stain Wood Conditioner (oil-based)
- Minwax Polyurethane Wood Finish (oil-based)
- Miter saw for cutting
- Wood screws
- Pocket hole drill jig
Step-by-Step Instructions:
1. Cut Your Wood Pieces
Start by cutting the wood to the required dimensions. For the chevron shelves, cut eight pieces to 1″ x 8″ x 17″ with a 30-degree bevel on both ends (to create that signature chevron design). The other shelves should be cut to 1″ x 8″ x 14-3/4″ with straight 90-degree edges.
Tip: For the angled chevron racks, ensure that both ends are cut at the same 30-degree angle to form the “V” shape.
2. Dry Fit the Pieces
Before drilling any holes, dry fit the pieces together. Place the shelves in between the side and middle panels of your bookshelf frame. Mark the spots where pocket holes will go, making sure they don’t overlap or interfere with one another.
3. Drill Pocket Holes
For each shelf, drill two pocket holes at each end (four holes per shelf). Sand all the edges smooth before moving on to the next step.
Pro Tip: For the chevron shelves, drill the pocket holes on the top side so they are hidden by items you place on the shelves. For the straight-edged shelves, make sure the pocket holes are placed underneath, keeping them out of sight.
4. Attach the Shelves
Using the pocket hole screws, attach the angled chevron shelves to the side panels of your bookshelf. Be sure to measure the spacing between each shelf (I suggest 6 inches between the top shelf and the next, with 12 inches between subsequent shelves). Repeat this process for all of the shelves, including the straight-edged ones.
5. Construct the Chevron Design
To complete the chevron look, carefully attach the last two angled shelves at the “V” point. Important: When screwing into the center shelf, start about 1/4″ higher than where you want it to meet. This way, the shelf will stay in place as the screws tighten and the angles come together perfectly.
6. Add the Top Panel
Once the chevron shelves are in place, secure the bookcase’s top panel. If needed, attach with screws or hammer and nails. Use a square tool to ensure the sides are perfectly aligned at 90-degree angles.
7. Attach the Bottom Shelves
Finally, attach the straight-edged shelves to the bottom. Use a square to ensure each shelf is level. You can even make some adjustments if necessary by measuring the spacing between shelves as you go.
8. Finishing Touches: Sanding & Staining
Once assembled, give your new shelf a smooth finish with medium-grit sandpaper (#120) and finer grit (#220). Wipe off any dust before moving on.
Next, apply Minwax Pre-Stain Wood Conditioner to help the wood absorb the stain evenly and avoid blotching. After letting it sit for 5-10 minutes, wipe off any excess.
Now, apply Minwax Wood Finish Stain in Unique Walnut 224, using a brush, foam brush, or even a cloth. Apply it in small sections, wiping off excess after each application. If you want a darker tone, leave it on for a few minutes longer.
Once the stain has dried, apply a coat of Minwax Polyurethane Wood Finish to protect your rack and give it a sleek, polished look.
9. Mounting Option
If you want your storage rack to be wall-mounted, drill at least four pocket holes in the side panels (two at the top and two at the bottom). Secure the rack to the wall using screws, and you’ll have a stylish storage unit that doesn’t take up any floor space!
10. Customize to Your Space
While this rack is perfect for holding wine bottles, don’t limit yourself! You can use it as a spray paint storage rack in your workshop, a pantry organizer for canned goods, or a stylish bookshelf for small items. With a little creativity, the possibilities are endless!
Conclusion
Creating your own chevron storage rack not only adds a modern touch to your home or workshop, but it also serves a practical purpose. Whether you need a wine rack, a paint organizer, or just an aesthetically pleasing piece of furniture, this DIY project is a fun and rewarding way to bring your space to life. Plus, you get the satisfaction of building something entirely your own!
